Real-time digital readouts of penetration load and depth for accurate monitoring.
Automated penetration rate control aligned with standard CBR test procedures.
Twin-column loading frame built for high-volume use and long-term structural stability.
Data-logging capability: device saves test results for traceability and quality-control.
Easy operation: set parameters, position specimen, press start — the machine handles the rest.
Optimal for compacted soils, sub-grade and base-course aggregates in pavement labs.
Load capacity and penetration speed suited for standard CBR testing protocols.
Precision penetration piston and platen system designed for standard CBR mold compatibility.
Digital interface simplifies data acquisition and reduces operator variation.
Built by Cantrol to meet laboratory requirements for CBR strength testing with consistency and reliability.
Laboratory determination of CBR values for road and pavement design.
Quality-control testing of sub-grade, sub-base and base materials.
Geotechnical and materials science labs assessing soil bearing capacity or stabilization treatments.
High-throughput labs where repeatability, digital output and automation are key.
| Model | 2814031 | 2814032 |
| Description | Digital CBR Testing Machine | Digital CBR Testing Machine |
| Capacity | 50 kN | 50 kN |
| Resolution | 20 N | 20 N |
| Power Supply | 120 V, 60Hz, 1ph | 220V, 50Hz, 1ph |
| Display | 4″ Touch Screen, Full Color | 4″ Touch Screen, Full Color |
| LoadRate | 50 mm/min (2 in/min) | 50 mm/min (2 in/min) |
| Software | Yes | Yes |
| DataSaving | yes | Yes |
| Displacement (Flowmeter) | 30×0.01 mm | 30×0.01 mm |
| Reporting Software | _ | _ |
| Dimension | 550x440x1280 mm | 550x440x1280 mm |
| Weight | 90 kg | 90 kg |
| Discription | Digital CBR (California Bearing Ratio) Testing Machine |
|---|---|
| Model | 2814031, 2814032 |
| Capacity | 50 kN |
| Resolution | 20 N |
| Power Supply | 2814031-110V, 60Hz, 1ph, 2814032-220V, 50Hz, 1ph |
| Display | 4" Touch Screen, Full Color |
| Load Rate | 50 mm/min (2 in/min) |
| Data Saving | yes |
| Displacement (Flowmeter) | 30×0.01 mm |
| Dimension | 550x440x1280 mm |
| Weight | 90 kg |
